High Density Polyethylene (HDPE) also called PE, It has many advantages including high impact resistance, wear resistance, anti-corrosion, self-lubrication, low-temperature resistance. Cause of these five advantages, HDPE board is widely used in industry parts.
our HDPE textured organ skin sheets is processing by our extruded machine , with a texture surface and can be process into many colors .
HDPE PE 100 PE500 Polyethylene extruded sheets extrusion machine :
Max width : 2700mm Length : no limit , any length as per customer requirement
Thickness :1-30mm
Standard size : 2000*1000mm , 2440*1220mm , 1000*1000mm ....customized size
single hdpe color sheet : black ,white , grey , red, yellow .....
Double colored hdpe sheets : .....
HDPE PE 100 PE500 Polyethylene Sheets technical data sheet
Property | Testing Method | Value |
Molecular weight (1E6 g/mol) | ASTM D6474 | 0.5-1 |
Density ( g/cm3) | ISO1183 | 0.95-0.98 |
Dynamic coefficient of friction | ISO8295 | <0.2 |
Hardness (Shore D) | ISO868 | 63-70 |
Elongation at break ( %) | ISO527 | ≥200 |
Tensile strength (N/mm2) | ASTM D638 | >15 |
Impact strength ( kJ/m2) | ISO179 | No Break |
Water absorption | ASTM D570 | <0.1 |
Surface resistivity ( Ohm) | IEC 93 | 1014 |
Temperature resistance ( ℃) | -200 to +80 | |
Melt Temperature ( ℃) | 130-140 | |
Flammability grade according to UL94 | HB | |
hdpe textured sheets can be used on truck bed liner with a good impact resistance and also wear resistance .
this goods is our Thailand customer order for their truck bed liner .
any more request , feel free contact with us freely .
