UHMWPE sheet is the best quality polyethylene available in harsh working environments and for multiple purposes. The applicability is very good in many difficult application conditions. It has a molecular weight of 3 to 9 million, ensuring that the ultra-high molecular weight polyethylene has sufficient strength to achieve wear resistance and impact resistance that other low-grade
polymer products cannot have.



  •  The anti-static PE-HMW sheets are often used for Transport- and warehouse equipment

  • Bottling Plants and Beverage Engineering

  • Chemical Engineering

  • The anti-static PE-HMW sheets are safe to use and in the Food Industry

  • Mechanical Engineering

  • The anti-static PE-HMW sheets are great for Bulk Goods Industry because of their anti-static properties

  • Electroplating


Thickness: 6 - 300mm

Width: max 2000mm


 Normal standard size:


Length(mm)

Width(mm)

Thickness(mm)

2000

1000

6-300

3000

1500

6-300

4700

1200

6-300

5000

1300

6-300

4500

2000

6-300

3050

1220

6-100

Black, Blue, Green, White, Yellow...




1.Weldable/Bendable - suitable for fabrication
2.UV Resistant - Black only
3.Physiologically inert - approved for food applications (Natural only)
4.Electrical insulation - it is a good insulator
5.Weatherproof - it doesn't absorb water
6.Chemical resistance - resists corrosive chemicals (e.g. Sulphuric Acid, Caustic Soda)

1. MINING INDUSTRY
REASONS:Good Impact Strength, High Wear Resistance and Low Friction Properties.
APPLICATIONS: Linings for Bunkers, Chutes and Railway Wagons, Conveyor Rollers, Scraper Blades, Impact Bars.

2. CHEMICAL INDUSTRY
REASONS: Excellent Chemical Resistance and Toughness, Easily Machined.
APPLICATIONS: Pump Housings, Seals, Gaskets, Stopcocks, Valves, Electroplating Barrels, Filter Press Plates.

3. FILTRATION INDUSTRY
REASONS: Excellent Chemical Resistance, Low Friction, High Wear
Resistance.
APPLICATIONS: Filter Plates, Vacuum Seal Strips, Support Rollers, Belt Slide Plates, Cloth
Guides, Belt Guide Rollers, Belt and Cloth Tensioners.
4. PAPER INDUSTRY
REASONS: Low Coefficient of Friction, High Wear Resistance.
APPLICATIONS: Suction Box Covers and Bars, Foils, Guide Blades, Slide Deckles, Rollers.

5. PORT, DOCK INSTALLATIONS, SHIPBUILDING
REASONS:Good Impact Strengths, Low Friction, UV. Resistance.
APPLICATIONS:Dock Fenders, Buffer Strips, Cable Guides, Weir Plates, Lock Gates.

6. BREWERY, BOTTLING AND CANNING
REASONS: High Wear Resistance, Low Friction, Good Impact Strengths, Food Approved.
APPLICATIONS: Wear Strips, Chain Guides, Starwheels, Can Guides, Chain Tensioners, Dead Plates, Feed worms, Bearings, Rollers.

7. FOOD AND PREPARATION
REASONS:F.D.A. Approval, Non - Stick, Good Impact Strengths.
APPLICATIONS: Food Preparation Tables, Cutting Boards, Stirring Paddles, Mincer
Rammers, Rolling Pins, Knife Holders, Butchers Blocks.
