Ultra High Molecular Weight Polyethylene (PE‐UHMW) occupies the extreme end of the polyethylene performance spectrum. With a molecular weight ranging from 3 to 7 million g/mol, PE‐UHMW linear polymer chains are 10 times longer than conventional High Density Polyethylene (HDPE).


This unique molecular structure gives PE‐UHMW it’s exceptional properties like below:

Density   : 0.92 – 0.96 g/cm3

Tensile strength at yield : 15 – 20 Mpa

Notched impact strength : 80 – 170 kJ/m2

Abrasion resistance (sand slurry test) : 70 – 120 %

Shore hardness D: 60 – 63o

Max. cont. temperature: 80°C

Abosn UHMWPE  properties have meet the full range of material flow,friction and wear challenge associated with bulk materials.


Material :PE500,PE1000,PE2000


1.Size:

2000x1000x(6-300)mm 2250x1000x(6-300)mm

2300x1200x(6-300)mm2500x1300x(6-300)mm

3050x1220x(6-300)mm3000x1500x(6-300)mm

4500x2000x(6-200)mm4700x1200x(6-150)mm

5000x1300x(6-180)mm6100x1800x(6-200)mm

Any size within the standard size is available


2.Color:

Black,Blue,Yellow,Green,White,Red,Orange ,any other color will be available


•High Abrasion Resistance

•High Impact Resistance

•Low Coefficient of Friction

•Chemical Resistant

•Lightweight

•Less expensive than stainless steel

•Excellent retrofit for protective linings


Coal bin liner/Silo liner/Hopper liner/Coal Chute Liner/bunker liner/hopper liner/granary plate/track liner/track bed liner/ HMWPE coal bunker liner board prevent cohere/ chute liner/ UHMWPE Plastic Dump Truck Liner.
